Home / Solar Ups / Microtek Solar PCU PWM 1135VA/1000W (12V)
Microtek Solar PCU PWM 1135VA/1000W (12V)
Microtek  |  Solar Ups

Microtek Solar PCU PWM 1135VA/1000W (12V)

PCU PWM 1450/12V In Stock
Rs. 18,250 Rs. 21,500 15% OFF
Full Product Catalog (Images + Specs)
Download Full Catalog
Scan to View on Mobile
Open your phone camera to share or browse link quickly.
Request Quote

Product Details

Microtek PWM BASED SOLAR PCU is designed to utilize maximum use of Solar Energy. If there is excess of Solar Energy Generation from PV then it charges the Battery and simultaneously it supplies the Power to the Load. While a solar PCU is similar to a solar inverter, there are a few differences. In a solar PCU, battery charging is very important during the day. Solar PCU controls the core and selects the charging source accordingly. Comes with a user that selects the energy-saving option to allow the user to choose the priority and save the bill. It also selects the AC output source from Solar or inverter or grid. In Energy Saver Mode first supplied to Solar, the battery is pre-charged and also supports the inverter to power electrical items. When the solar power stops, the PCU begins to use stored energy from the battery. When the stored power is used to a certain level, the inverter switches to the grid. The main focus here is to save on the cost of electricity bills. In a solar PCU, solar energy is very important, and in the absence of solar energy the energy comes from the electricity used. Solar PCUs are designed for maximum solar gain and therefore reduce energy costs.
  • High-Efficiency Solar PCU (1135VA / 1000W): Designed for reliable power backup for homes, offices, and shops with Pure Sine Wave technology that protects sensitive electronics.
  • Powerful Dual Charging System: Supports 10A/14A mains charging and 40A solar charging, offering flexible and fast charging through grid or solar.
  • Optimized Solar Utilization: Prioritizes solar power usage to reduce electricity consumption and extend battery backup life.
  • 12V Battery System Compatibility: Supports single battery configuration with strong 53A full-load battery current.
  • Stable Output: Provides 230V on no-load and 180V at full load, ensuring safe operation of appliances like LED TVs, Fans, Lights, CCTV, and Computers.
  • Durable & Compact Design: Rugged structure with compact size 38.4cm × 37.5cm × 19.4cm and 10kg weight, ideal for home & professional usage
